JST S8B-ZR (LF)(SN) ZH Pin Strip 8-Pin 1.50mm Pitch Detachable Connector

Image Representative of Range

JST S8B-ZR (LF)(SN) ZH Pin Strip 8-Pin 1.50mm Pitch Detachable Connector

JST
Order Code:

04-4944

Brand: JST MPN: S8B-ZR (LF)(SN) EAN-13: 2050000918292
Qty Unit Price (Ex VAT)
10+ £0.574
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
125 in stock, despatched in 4 working days

The JST S8B-ZR (LF)(SN) is a precision-built pin strip featuring 8 angled pins with a contact spacing of 1.50 mm. Manufactured by J.S.T., this compact connector is typically used in printed circuit board applications due to its dimensions of 13.5x3.5x7.2 mm. Ideal for electronics and components that require reliable and efficient connectivity.
Type Built-in pin strip (precision)
Number of Positions 8
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Colour Ecru
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Phosphor bronze
Cross Section 1.50mm
Dimensions (L x W x H) 13.5 x 3.5 x 6.4 mm
Height 6.4mm
Industrial packaging No
Insulation Material Polyamide
Length 13.5mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 1A
Nominal Voltage 50V AC
Pin Ø 0.5mm
Pin shape Circular
Pins per row 8
Series ZH
Width 3.5mm
