JST PHR-7 Socket Housing Cable 7 Pins 2mm Pin Spacing Click Lock

The JST PHR-7 is a socket housing cable with a total of 7 pins, featuring a contact spacing of 2 mm. Manufactured by J.S.T., it has dimensions of 15.8 x 4.5 x 6.4 mm, making it suitable for compact PCB connector applications. Typical uses include electronic assemblies where reliable, low-profile connections are essential.

Type	Socket housing cable
Pitch	2mm
Number of Ways	7
Number of Rows	1
Mounting Type	Cable mount
Mounting Direction	Straight
Case Material	Polyamide
Colour	Ecru
Connection	Crimp
Connector contact surface	Tin plated
Connector System	wire-to-board
Connector Type	Socket, straight
Contact Material	Copper alloy
Cross Section	0.05 - 22mm²
CS	2mm
Dimensions	(L x W x H) 15.8 x 15.8 x 9.4 mm
Height	9.4mm
Industrial packaging	No
Insulation Material	Polyamide
Length	15.8mm
Material (details)	PA 66 UL94V-0
Misc Attribute 1	Connector pin strip, straight
Nominal Current	2A
Nominal current - rounded value	2A
Nominal current (details)	2A
Nominal voltage (details)	voltage:100V AC
Pins per row	7
Series	PHR
Width	15.8mm
