The JST built-in pin strip is a precision connector with 8 pins and a contact spacing of 1.50 mm. Manufactured by JST, this component measures 13.5x3.5x7.2 mm and is categorized under PCB connectors, suitable for creating reliable connections on printed circuit boards. Its straight 8-pole configuration makes it ideal for use in compact electronic assemblies and modular circuit designs.
| No. of rows |
1 |
| Board contact surface |
Tin plated |
| Case material |
Polyamide |
| Connector contact surface |
Tin plated |
| Connector orientation |
Perpendicular (to the PCB) |
| Connector system |
wire-to-board |
| Connector type |
Pin strip, straight |
| Contact material |
Phosphor bronze |
| Cross section |
0.032 - 0.13mm² |
| CS |
1.50mm |
| Dim |
(L x W x H) 13.5 x 3.5 x 7.2 mm |
| Factory colour |
Ecru |
| Height |
7.2mm |
| Industrial packaging |
No |
| Insulation material |
Polyamide |
| Length |
13.5mm |
| Manufacturer part # |
B8B-ZR (LF)(SN) |
| Material (details) |
PA 66 UL94V-0 |
| Misc Attribute 1 |
Connector pin strip, straight |
| Misc Attribute 2 |
B8B-ZR (LF)(SN) |
| Nominal current |
1A |
| Nominal current - rounded value |
1A |
| Nominal current (details) |
1A |
| Nominal voltage (details) |
50V AC |
| Pin Ø |
0.5mm |
| Pin shape |
Circular |
| Pins |
8 |
| Pins per row |
8 |
| RoHS-compliant |
Yes |
| Series |
ZH |
| Total number of pins |
8 |
| Type |
Built-in pin strip (precision) |
| Width |
3.5mm |
