JST B3B-ZR (LF)(SN) ZH Pin Strip 3 Pins 1.50mm Spacing PCB Connection

Image Representative of Range

JST B3B-ZR (LF)(SN) ZH Pin Strip 3 Pins 1.50mm Spacing PCB Connection

JST
Standard range
Order Code:

04-4864

Brand: JST MPN: B3B-ZR (LF)(SN)
Qty Unit Price (Ex VAT)
1+ £0.264
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
228 in stock, despatched in 4 working days

This JST connector pin strip, model B3B-ZR (LF)(SN), features three pins with a contact spacing of 1.50 mm. It is a straight precision component, measuring 6x3.5x7.2 mm. Typically used in PCB applications, this component is essential in connecting circuits efficiently.
No. of rows 1
Board contact surface Tin plated
Case material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Pin strip, straight
Contact material Phosphor bronze
Cross section 0.032 - 0.13mm²
CS 1.50mm
Dim (L x W x H) 6 x 3.5 x 7.2 mm
Factory colour Ecru
Height 7.2mm
Industrial packaging No
Insulation material Polyamide
Length 6mm
Manufacturer part # B3B-ZR (LF)(SN)
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Misc Attribute 2 B3B-ZR (LF)(SN)
Nominal current 1A
Nominal current - rounded value 1A
Nominal current (details) 1A
Nominal voltage (details) 50V AC
Pin Ø 0.5mm
Pin shape Circular
Pins 3
Pins per row 3
RoHS-compliant Yes
Series ZH
Total number of pins 3
Type Built-in pin strip (precision)
Width 3.5mm
