JST 801136 XH Pin Strip 7 Pins 2.50mm Spacing Pre-Tin Coated

Image Representative of Range

JST 801136 XH Pin Strip 7 Pins 2.50mm Spacing Pre-Tin Coated

JST
Order Code:

04-4833

Brand: JST MPN: 801136 EAN-13: 2050000917653
Qty Unit Price (Ex VAT)
20+ £0.357
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
187 in stock, despatched in 4 working days

The JST pin strip model 801136 features 7 pins with a contact spacing of 2.50 mm and dimensions of 19.9x5.75x10.4 mm, making it suitable for various PCB applications. Manufactured by JST, this straight pin strip connectors are commonly used in electronic and electrical circuits for reliable connections. Typical applications include consumer electronics, appliances, and industrial control systems.
Type Pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.08 -0.33mm²
CS 2.50mm
Dim (L x W x H) 19.9 x 5.75 x 10.4 mm
Factory colour Ecru
Height 10.4mm
Industrial packaging No
Insulation Material Polyamide
Length 19.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pin Ø 0.64mm
Pin shape Square
Pins 7
Pins per row 7
Series XH
Total number of pins 7
Width 5.75mm
