JST 801098 XH Pin Strip 7-Pin 2.50mm Pre-Tinned 1pc Detachable Connection

Image Representative of Range

JST 801098 XH Pin Strip 7-Pin 2.50mm Pre-Tinned 1pc Detachable Connection

JST
Order Code:

04-4832

Brand: JST MPN: 801098 EAN-13: 2050000917745
Qty Unit Price (Ex VAT)
10+ £0.419
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
51 available to back orderBack-order availability date - 10/01/2026

The JST pin strip (standard) XH features a total of 7 pins with a contact spacing of 2.50 mm. Manufactured by JST, this angled header is sized at 19.9x5.75x10.4 mm, making it suitable for compact PCB connector applications. It is typically used in electronic components, providing reliable connections on printed circuit boards.
Type Pin strip (standard)
Number of Positions 7
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Colour Ecru
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Phosphor bronze
Cross Section 2.50mm
Dimensions (L x W x H) 19.9 x 5.75 x 10.4 mm
Height 10.4mm
Industrial packaging No
Insulation Material Polyamide
Length 19.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 3A
Nominal Voltage 250V AC
Pin Ø 0.64mm
Pin shape Square
Pins per row 7
Series XH
Width 5.75mm
