JST 800923 XH Pin Strip 10 Pins 2.50mm Pre-Tin Reverse Voltage Protection

Image Representative of Range

JST 800923 XH Pin Strip 10 Pins 2.50mm Pre-Tin Reverse Voltage Protection

JST
Order Code:

04-4828

Brand: JST MPN: 800923 EAN-13: 2050000917769
Qty Unit Price (Ex VAT)
10+ £0.574
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
90 in stock, despatched in 4 working days

JST manufactures a 10-pin angled pin strip with a contact spacing of 2.50 mm. The connector strip, measuring 27.4x5.75x10.4 mm, is typically used in PCB applications. It is suitable for connecting components in electronic devices.
Type Pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Phosphor bronze
Cross Section 0.08 -0.33mm²
CS 2.50mm
Dim (L x W x H) 27.4 x 5.75 x 10.4 mm
Factory colour Ecru
Height 10.4mm
Industrial packaging No
Insulation Material Polyamide
Length 27.4mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pin Ø 0.64mm
Pin shape Square
Pins 10
Pins per row 10
Series XH
Total number of pins 10
Width 5.75mm
