JST 800529 XH Pin Strip 4-Pin 2.50mm Pre-tin Coated with Audible Click

Image Representative of Range

JST 800529 XH Pin Strip 4-Pin 2.50mm Pre-tin Coated with Audible Click

JST
Order Code:

04-4822

Brand: JST MPN: 800529 EAN-13: 2050000917714
Qty Unit Price (Ex VAT)
20+ £0.264
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
58 in stock, despatched in 4 working days

JST's pin strip standard XH with part number 800529 features four pins and a contact spacing of 2.50 mm. Measuring 12.4x5.75x10.4 mm, its angled design is ideal for printed circuit board connections. These connectors are commonly used in electronic components, facilitating efficient and secure PCB connections.
Type Pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Phosphor bronze
Cross Section 0.08 -0.33mm²
CS 2.50mm
Dim (L x W x H) 12.4 x 5.75 x 10.4 mm
Factory colour Ecru
Height 10.4mm
Industrial packaging No
Insulation Material Polyamide
Length 12.4mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pin Ø 0.64mm
Pin shape Square
Pins 4
Pins per row 4
Series XH
Total number of pins 4
Width 5.75mm
