JST 800330 XH Pin Strip 4 Pins 2.50mm Spacing Pre-Tin Solderable

Image Representative of Range

JST 800330 XH Pin Strip 4 Pins 2.50mm Spacing Pre-Tin Solderable

JST
Order Code:

04-4819

Brand: JST MPN: 800330 EAN-13: 2050000918780
Qty Unit Price (Ex VAT)
20+ £0.217
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
18 in stock, despatched in 4 working days

JST manufactures the XH pin strip connector with four pins and a contact spacing of 2.50 mm. This connector, commonly used in PCB applications, measures 12.4x5.75x10.4mm, making it suitable for compact electronic assemblies. The straight pin configuration is ideal for general electronics and circuitry projects.
Type Pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.08 -0.33mm²
CS 2.50mm
Dim (L x W x H) 12.4 x 5.75 x 10.4 mm
Factory colour Ecru
Height 10.4mm
Industrial packaging No
Insulation Material Polyamide
Length 12.4mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Misc Attribute 2 B4B-XH-A
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pin Ø 0.64mm
Pin shape Square
Pins 4
Pins per row 4
Series XH
Total number of pins 4
Width 5.75mm
