JST 800300 XH Pin Strip 12 Pins 2.50mm Click Lock Tin-Coated

Image Representative of Range

JST 800300 XH Pin Strip 12 Pins 2.50mm Click Lock Tin-Coated

JST
Order Code:

04-4818

Brand: JST MPN: 800300 EAN-13: 2050000917684
Qty Unit Price (Ex VAT)
10+ £0.651
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
59 in stock, despatched in 4 working days

The JST pin strip (standard) XH features 12 pins with a contact spacing of 2.50 mm, and its dimensions are 32.4x5.75x10.4 mm. It is commonly used in PCB connector applications where compact and reliable connections are needed. The part number 800300 indicates a product suitable for various electronic projects, ensuring secure component connections.
Type Pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.08 -0.33mm²
CS 2.50mm
Dim (L x W x H) 32.4 x 5.75 x 10.4 mm
Factory colour Ecru
Height 10.4mm
Industrial packaging No
Insulation Material Polyamide
Length 32.4mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pin Ø 0.64mm
Pin shape Square
Pins 12
Pins per row 12
Series XH
Total number of pins 12
Width 5.75mm
