JST 800184 XH Pin Strip 3 Pins 2.50mm Pre-Tin Coated Click-Locking

Image Representative of Range

JST 800184 XH Pin Strip 3 Pins 2.50mm Pre-Tin Coated Click-Locking

JST
Standard range
Order Code:

04-4813

Brand: JST MPN: 800184
Qty Unit Price (Ex VAT)
1+ £0.171
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1,078 in stock, despatched in 4 working days

The JST pin strip XH, part number 800184, is a straight connector with 3 pins and a contact spacing of 2.50 mm. Its dimensions are 9.9x5.75x10.4 mm, making it suitable for compact PCB applications. Typically used in electronic projects, this component facilitates reliable connections in various devices.
No. of rows 1
Board contact surface Tin plated
Case material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Pin strip, straight
Contact material Phosphor bronze
Cross section 0.08 -0.33mm²
CS 2.50mm
Dim (L x W x H) 9.9 x 5.75 x 10.4 mm
Factory colour Ecru
Height 10.4mm
Industrial packaging No
Insulation material Polyamide
Length 9.9mm
Manufacturer part # 800184
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Misc Attribute 2 B3B-XH-A (LF)(SN)
Nominal current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pin Ø 0.64mm
Pin shape Square
Pins 3
Pins per row 3
RoHS-compliant Yes
Series XH
Total number of pins 3
Type Pin strip (standard)
Width 5.75mm
