Idec RV8H-S-D24 RV8H Series Industrial relay 24V DC 6A General Purpose

Idec's RV8H-S-D24 is a general-purpose power relay that is part of the RV8H Series, designed for industrial applications requiring reliable switching capabilities. The relay operates at a nominal voltage of 24 V DC and can handle a maximum switching current of 6 A, making it suitable for various control and automation tasks. It features a robust construction that ensures durability and efficiency in demanding environments. Typical applications include use in manufacturing equipment, automation systems, and other industrial control circuits where precise relay switching is essential. The relay can also be used in conjunction with suitable relay sockets to facilitate easy installation and maintenance in electrical panels.

Coil Voltage	24V
Switching Current	6A
Colour	Black
Contact Material	Silver alloy (flash gold plated)
Content	1
Dimensions	(L x W x H) 93.4 x 75.6 x 6.1 mm
Durability	At least 10 000 000 inserts
Electrical lifespan	Min. 10 000 - 30 000 inserts
Fall Time	20ms
Height	6.1mm
IP Rating	IP67
Length	93.4mm
Max. pick-up voltage	26.4V DC
Maximum Temperature	85°C
Min. pick-up voltage	21.6V DC
Minimum Temperature	-40°C
Mounting Type	Socket
Nominal Voltage	24V DC
Product Type	Industrial relay
Resistance (coil)	2.270Ω
Response Time	15ms
Type	RV8H Series
Weight	26g
Width	75.6mm
