Hammond HP50PCLG IP66 Non-Metallic Hole Plug 32mm Diameter

Hammond
MPN
HP50PCLG
Brand
Hammond
UPC-12
623980101613
Order Code
31-1808
Country of Origin
USA
View Full Product Range (7)
Qty Unit Price (Ex VAT)
1+ £11.41
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Despatched within 1 working day - 6 in stockBack-order availability date - 04/07/2026

The Hammond Type 4X HPN4PC Series Hole Plug is designed to seal unused pushbutton holes, conduit openings or knock-out holes against the ingress of dust, oil and water.

Compatible with enclosure wall thickness of 1.6mm to 6.35mm.

Recognised component for use with UL & CSA listed enclosures, Type 1, 3, 3R, 4, 4X.



  • 32mm Diameter
  • RAL7035 Light Grey
  • Moulded Polycarbonate
  • 24mm Minimum Hole Diameter
  • 21mm Maximum Hole Diameter
  • Neoprene/EPDM Gasket
  • Self centring, anti-rotational design
  • Easy one person installation
  • No tools required

    • Available in 7 sizes.

    Designed to maintain the IP66/NEMA 4X rating of Enclosure once fitted.

    Hammond enclosure modification


    Type Hole Plug
    Material Polycarbonate
    Enclosure Width 32mm
    Ingress Protection Rating IP66
    Colour Light Grey
    Diameter 32mm
    External Features Neoprene/EDPM gasket
    Series HPN4PC
