GW Instek AFG-2105 Arbitrary Function Generator - 5 MHz 1-channel

Name: GW Instek AFG-2105 Arbitrary Function Generator - 5 MHz 1-channel
Brand: GW Instek
Price: 282.43 GBP
Availability: InStock

Standard range

Order Code:

11-9311

Brand: GW Instek MPN: 01AF210500GS EAN-13: 4016138757132

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (2)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£282.43

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

2 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The AFG -2105 function generator with direct digital signal generation (DDS) offers a bandwidth of 5 MHz. The equipment includes the standard signals: sine, square, ramp, noise and 20 MSa/s arbitrary waveform with 10-bit vertical resolution. In addition, the functions AM/FM/FSK modulation, sweep and frequency counter. The 8.89 cm large LCD colour monitor shows all Waveform parameters and settings. A USB interface can be used for the remote control with a computer. The arbitrary waveform can be used via the free downloadable PC ® software is generated and transmitted via USB to the generator.
