Fujitsu FTR-K1AK012T Relay 12V DC 16A 15.7mm Tall 5kV Insulation

Fujitsu
Standard range
Order Code:

09-1676

Brand: Fujitsu MPN: FTR-K1AK012T EAN-13: 2050001760524
Qty Unit Price (Ex VAT)
1+ £1.43
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
252 in stock, despatched in 4 working days

The Fujitsu FTR-K1AK012T is a PCB mount relay designed for a 12 V DC coil and can handle a current of 16 A. This mini relay is ideal for integration in compact printed circuit board applications, offering reliable performance in small electronic devices. It is suitable for use in automotive, industrial control, and home appliance applications.
Height 15.7mm
Length 29mm
Type PCB relay
Width 12.7mm
Coil nominal voltage 12V DC
Connection Solder pins
Contact material AgSnO2
Contact type 1 maker
Control mode monostable, 1 coil
Dim (L x W x H) 29 x 12.7 x 15.7 mm
Durability 20 x 106 switching cycles
Electrical lifespan 100 x 103 switching cycles
Max. pick-up voltage 29.4V DC
Max. temperature +85°C
Min. pick-up voltage 8.4V DC
Min. temperature -40°C
Misc Attribute FTR-K1AK012T
Resistance (coil) 360Ω
RoHS-compliant Yes
Switching current (max.) 16A
