The Finder 55.34.9.024.0090 is a plug-in relay rated at 24 V DC and 7 A, featuring four change-over contacts. It is commonly used in controlling circuits on printed circuit boards, ensuring reliable connections. Typical applications include automation systems, industrial control panels, and equipment requiring precise switching.
| Coil Voltage |
24V DC |
| Contact Configuration |
4CO (4PDT) |
| Switching Current |
7A |
| Coil Resistance |
600O |
| Complete with socket |
false |
| Connection |
Type C CEE 7/16 plug 2mm |
| Contact Material |
AgNi |
| Control Mode |
monostable, 1 coil |
| Degree of protection (IP) |
N/A |
| Depth |
27.7mm |
| Dimensions |
(L x W x H) 27.7 x 20.7 x 37.2 mm |
| Drive, polarization |
Polarized |
| Drive, switching attitude |
Mono stable |
| Durability |
(AC/DC) 100 x 103/200 x 103 switching cycles |
| Height |
37.2mm |
| Length |
27.7mm |
| Material contact |
Other copper alloys |
| Material of contact insert |
Duroplast |
| Material of contact surface |
Untreated |
| Max. pick-up Voltage |
26.4V DC |
| Max. switching capacity |
1750VA |
| Max. temperature |
+85°C |
| Min. pick-up Voltage |
19.2V DC |
| Minimum Temperature |
-40°C |
| Mounting Type |
Plug-in |
| Nominal Current |
7A |
| Number of contacts as change-over contact |
4 |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
0 |
| Rated control supply voltage DC |
24 - 24V |
| Switching Voltage |
250V AC |
| Switching Voltage Max |
250V AC |
| Temperature Range |
-40 - +85°C |
| Type |
Plug-in relay |
| Type of electric connection |
Plug-in connection |
| Type of switch contact |
Single contact |
| Voltage type for actuating |
DC |
| Width |
20.7mm |
| With detachable clamps |
N/A |
| With forced-guided contacts |
false |
| With LED indication |
true |
