The Finder 43.41.7.005.0000 PCB relay is a compact component capable of handling 5 V DC and 10 A with a change-over contact. Its reliable design makes it suitable for use in printed circuit boards across various electronic applications. Commonly used in automation systems, this relay ensures efficient control and switching of electrical circuits.
| Coil Voltage |
5V DC |
| Contact Configuration |
1CO (SPDT) |
| Switching Current |
10A |
| Coil Resistance |
130Ω |
| Complete with socket |
false |
| Contact Material |
AgNi |
| Degree of protection (IP) |
N/A |
| Depth |
30.2mm |
| Dimensions |
(L x W x H) 30.20 x 10.20 x 15.40 mm |
| Drive, polarization |
Polarity free |
| Drive, switching attitude |
Mono stable |
| Durability |
(AC/DC) 10 x 106 switching operations |
| Height |
15.40mm |
| IP Rating |
Relay protection type RT II |
| Length |
30.2mm |
| Material contact |
Other copper alloys |
| Material of contact insert |
Thermoplastic |
| Material of contact surface |
Untreated |
| Max. pick-up Voltage |
7.5V DC |
| Max. switching capacity |
2500VA |
| Maximum Temperature |
+85°C |
| Min. pick-up Voltage |
3.5V DC |
| Min. temperature |
-40°C |
| Minimum Operating Temperature |
-40°C |
| Misc Attribute 2 |
DC-coil |
| Mounting Type |
PCB |
| Nominal Current |
10A |
| Number of contacts as change-over contact |
1 |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
0 |
| Rated control supply voltage DC |
5 - 5V |
| Switching Voltage Max |
400V AC |
| Type |
PCB relay |
| Type of electric connection |
PCB connection |
| Type of switch contact |
Single contact |
| Voltage type for actuating |
DC |
| Width |
10.2mm |
| With detachable clamps |
N/A |
| With forced-guided contacts |
false |
| With LED indication |
false |
