Finder 40.31.6.012.0000 PCB Relay 12V AC/DC 10A 1CO contact AgNi 3.5mm pitch

Image Representative of Range

Finder 40.31.6.012.0000 PCB Relay 12V AC/DC 10A 1CO contact AgNi 3.5mm pitch

Finder
Order Code:

03-3650

Brand: Finder MPN: 40.31.6.012.0000 EAN-13: 2050011615760
Qty Unit Price (Ex VAT)
1+ £7.63
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back order

The Finder 40.31.6.012.0000 PCB relay is designed for both 12 V AC and 12 V DC applications, providing reliable switching with a 10 A capacity. It features a single change-over contact and is suitable for printed circuit board mounting. This mini relay is ideal for use in automation systems, industrial equipment, and electronic control panels.
Coil Voltage 12V AC/DC
Contact Configuration 1CO (SPDT)
Switching Current 10A
Complete with socket false
Connection Print
Degree of protection (IP) N/A
Depth 29mm
Dimensions (W x H x D) 12.4 x 25 x 29 mm
Drive, polarization Polarized
Drive, switching attitude Bistable
Height 25mm
IP Rating IP20
Material contact Other copper alloys
Material of contact insert Thermoplastic
Material of contact surface Untreated
Mounting Type PCB
Nominal Current 10A
Number of contacts as change-over contact 1
Number of contacts as normally closed contact 0
Number of contacts as normally open contact 0
Rated control supply voltage AC 50 Hz 12 - 12V
Rated control supply voltage AC 60 Hz 12 - 12V
Rated control supply voltage DC 12 - 12V
Type PCB relay
Type of electric connection Plug-in connection
Type of switch contact N/A
Voltage type for actuating AC/DC
Width 12.4mm
With detachable clamps N/A
With forced-guided contacts false
With LED indication false
