Finder 38.61.0.125.0060 Crossbar Switch 110 V DC/AC 6 A 1 changeover

Finder's Crossbar switch, part number 38.61.0.125.0060, is an interface relay designed for use with 110 V DC/AC and can handle up to 6 A. It features one change-over contact, making it suitable for switching applications in automation and control systems. This reliable component is ideal for industrial use where robust and efficient switching is required.

Type	Crossbar switch
Complete with socket	true
Connection	Spring-loaded connector
Contact Type	1 change-over
Degree of protection (IP)	IP20
Depth	76mm
Dim	(W x H x D) 6.2 x 93.6 x 76 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	93.6mm
IP Rating	IP20
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Untreated
Nominal Current	6A
Nominal Voltage	110V DC/AC
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage AC 50 Hz	110 - 125V
Rated control supply voltage AC 60 Hz	110 - 125V
Rated control supply voltage DC	110 - 125V
Switching current (max.)	6A
Type of electric connection	Spring clamp connection
Type of switch contact	Single contact
Voltage type for actuating	AC/DC
Width	6.2mm
With detachable clamps	false
With forced-guided contacts	false
With LED indication	true
