Finder 38.51.3.125.0060 Crossbar Switch 110V AC 6A DIN Rail with LED

The Finder 38.51.3.125.0060 Crossbar switch is a reliable interface relay operating at 110 V AC and 6 A. It features a single change-over contact, making it suitable for switching applications in automation and control systems. Typical uses include industrial machinery, electrical panels, and other automated equipment.

Type	Crossbar switch
Complete with socket	true
Connection	Screw terminal
Contact Type	1 change-over
Degree of protection (IP)	IP20
Depth	75.6mm
Dim	(W x H x D) 6.2 x 87.9 x 75.6 mm
Drive, polarization	Polarized
Drive, switching attitude	Mono stable
Height	87.9mm
IP Rating	IP20
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Untreated
Nominal Current	6A
Nominal Voltage	110V AC
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage AC 50 Hz	125 - 125V
Rated control supply voltage AC 60 Hz	110 - 125V
Rated control supply voltage DC	110 - 125V
Switching current (max.)	6A
Type of electric connection	Screw connection
Type of switch contact	Single contact
Voltage type for actuating	AC/DC
Width	6.2mm
With detachable clamps	false
With forced-guided contacts	false
With LED indication	true
