Finder 34.51pcB Relay 48V DC 6A 1 changeover contact AgNi RT II

The Finder 34.51.7.048.0019 PCB relay is a compact relay designed for printed circuit boards, operating at 48 V DC with a switching capability of 6 A. Its 1 change-over contact makes it suitable for diverse electronic applications, including industrial automation and control systems. This reliable relay is manufactured by Finder and is ideal for miniaturised designs requiring efficient and robust switching.

Coil Voltage	48V
Contact Configuration	1CO (SPDT)
Switching Current	6A
Complete with socket	false
Degree of protection (IP)	N/A
Depth	28mm
Dimensions	(W x H x D) 15 x 5 x 28 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	5mm
IP Rating	IP20
Length	28.0mm
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Untreated
Mounting Type	PCB
Nominal Current	6A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	48 - 48V
Type	PCB relay
Type of electric connection	PCB connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	15mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	false
