FCI 86093967113755ELF Edge Connector 96 Pins 3 Rows 1pc

Image Representative of Range

FCI 86093967113755ELF Edge Connector 96 Pins 3 Rows 1pc

FCI
Standard range
Order Code:

03-0923

Brand: FCI MPN: 86093967113755ELF
Qty Unit Price (Ex VAT)
1+ £3.82
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
23 in stock, despatched in 4 working days

The FCI 86093967113755ELF is an edge connector with 96 pins and 3 rows, suitable for high-density connection applications. Manufactured by FCI, it is part of the DIN System 23 range, commonly used in Printed Circuit Boards (PCBs) where reliable and compact connections are required. Typical applications include computer systems and industrial electronics, where efficient power and signal transmission are critical.
Type Edge connector (pins)
Case material Thermoplastic UL94V-O
Certification marks DIN 41612
Configuration (a+b+c)
Connection Print
Connector orientation Parallel (to the PCB)
Connector type Multipole connector, right angle
Contact material Copper alloy
Contact surface Gold plated
CS 2.54mm
Dim (L x W x H) 10.2 x 94 x 15.28 mm
DIN standard C
Factory colour Grey
Height 15.28mm
Length 10.2mm
Manufacturer part # 86093967113755ELF
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute DIN (PCB, System 23, IDC, Power)
No. of rows 3
Nominal current 1.5A
Nominal current - rounded value 1.5A
Nominal voltage 1000V
Number of pins 96
Pins per row 32
Total no. of pins 96
Width 94mm
