econ connect W33S8 Pin Strip 1 row 8 pins standard bulk 1pc

Manufactured by econ connect, the W33S8 pin strip (standard) features 1 row with 8 pins per row and is available as 1 piece in bulk. This connector is typically used in electronic applications for making reliable circuit connections on printed circuit boards. The compact design is well-suited for efficient connectivity solutions in various electronic devices.

Type	Pin strip (standard)
Number of Positions	8
Number of Rows	1
Case Material	Nylon (NL)
Colour	White
Connection	Solder pins
Connector orientation	Perpendicular (to the PCB)
Connector Type	Pin strip, straight
Contact Material	Brass
Contact surface	Tin plated
Cross Section	2.5mm
Dimensions	(W x H) 5.7 mm x 7 mm
Height	7mm
Maximum Temperature	85°C
Min. temperature	-25°C
Nominal Current	3A
Nominal Voltage	250V
Packaging Type	Bulk
Pin length (PCB)	3.4mm
Pin shape	Square
Pins per row	8
Separable	No
Width	5.7mm
