econ connect W33R10 Pin Strip 1 row 10 pins bulk 1 piece

econ connect
Standard range
Order Code:

02-7734

Brand: econ connect MPN: W33R10
Qty Unit Price (Ex VAT)
1+ £0.115
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
10 in stock, despatched in 4 working days

The econ connect W33R10 is a standard pin strip with one row containing ten pins. This component is typically used in electronic circuit boards for establishing connections. It is available in bulk as a single piece, making it suitable for both prototyping and small-scale production.
Case material Nylon (NL)
Connection Solder pins
Connector orientation Parallel (to the PCB)
Connector type Pin strip, right angle
Contact material Brass
Contact surface Tin plated
CS 2.5mm
Dim (W x H) 5.85 mm x 11.2 mm
Factory colour White
Height 11.2mm
Manufacturer part # W33R10
Max. temperature 85°C
Min. temperature -25°C
Misc Attribute W33R10
No. of rows 1
Nominal current 3A
Nominal current - rounded value 3A
Nominal voltage 250V
Packaging type Bulk
Pin length (PCB) 3.4mm
Pin shape Square
Pins per row 10
Separable No
Total number of pins 10
Type Pin strip (standard)
Width 5.85mm
