econ connect SAS28S6 SIL Socket precision 1 row 6 pins 1pc

Image Representative of Range

econ connect SAS28S6 SIL Socket precision 1 row 6 pins 1pc

econ connect
Order Code:

02-7592

Brand: econ connect MPN: SAS28S6 EAN-13: 2050005791166
Qty Unit Price (Ex VAT)
10+ £0.531
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
175 in stock, despatched in 4 working days

The econ connect SAS28S6 SIL socket (precision) is a single-row connector featuring 6 pins, designed for precise electronic applications. Manufactured by econ connect, it ensures reliable connectivity in compact circuit assemblies. Typically used in prototype boards and testing environments, it aids in efficient component interfacing and signal routing.
Type SIL socket (precision)
Number of Positions 6
Number of Rows 1
Orientation Perpendicular (to the PCB)
Board contact surface Tin plated
Case Material PPS
Colour Black
Connection Solder pins
Connector contact surface Gold plated
Connector system wire-to-board
Contact Material Copper alloy
CS 2mm
Max. temperature 105°C
Min. temperature -40°C
Nominal Current 3A
Nominal current - rounded value 3A
Nominal Voltage 60V
Pin Ø 0.43mm
Pin shape Circular
Pins per row 6
