econ connect PV6OZ Pin Connector 2.54mm 6 pins 2 rows 1pc tray

econ connect
Standard range
Order Code:

02-7589

Brand: econ connect MPN: PV6OZ
Qty Unit Price (Ex VAT)
1+ £0.485
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
401 in stock, despatched in 4 working days

The econ connect PV6OZ pin connector features a contact spacing of 2.54 mm with a total of 6 pins arranged in 2 rows. It is typically used in electronic and electrical applications for connecting circuit components efficiently. This connector is supplied in a tray and is ideal for prototyping and small-scale projects.
No. of rows 2
Board contact surface Gold plated
Case material PBT
Connection Cut & Clip
Connector contact surface Gold plated
Connector orientation Perpendicular (to the PCB)
Connector type Power strip
Contact material Brass
CS 2.54mm
Dim (L x W x H) 7 x 12.32 x 10.5 mm
Factory colour Black
Height 10.5mm
Length 7mm
Manufacturer part # PV6OZ
Max. temperature +105°C
Min. temperature -40°C
Misc Attribute PV6OZ
Nominal current 1A
Nominal voltage 500V AC
Packaging type Tray
Pins per row 3
RoHS-compliant Yes
Total number of pins 6
Type Pin connector
Width 12.32mm
