econ connect PV50OZ Pin Connector 50 pins 2.54mm spacing 2 rows 1pc tray

econ connect
Order Code:

02-7586

Brand: econ connect MPN: PV50OZ EAN-13: 2050003718233
Qty Unit Price (Ex VAT)
10+ £0.548
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
43 in stock, despatched in 4 working days

The econ connect PV50OZ pin connector, with contact spacing of 2.54 mm, features 50 pins arranged in 2 rows. Manufactured by econ connect, this connector is typically used in electronic devices requiring precise connection configurations. Its compact design makes it suitable for high-density applications in trays.
Type Pin connector
Number of Rows 2
Board contact surface Gold plated
Case Material PBT
Colour Black
Connection Cut & Clip
Connector contact surface Gold plated
Connector orientation Perpendicular (to the PCB)
Connector Type Power strip
Contact Material Brass
Cross Section 2.54mm
Dimensions (L x W x H) 7 x 68.2 x 10.5 mm
Height 10.5mm
Length 7mm
Max. temperature +105°C
Min. temperature -40°C
Nominal Current 1A
Nominal Voltage 500V AC
Packaging Type Tray
Pins per row 25
Total number of pins 50
Width 68.2mm
