econ connect PV34OZ Pin Connector 2.54mm spacing 34 pins 2 rows tray 1pc

econ connect
Standard range
Order Code:

02-7582

Brand: econ connect MPN: PV34OZ
Qty Unit Price (Ex VAT)
1+ £0.332
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
102 in stock, despatched in 4 working days

The econ connect PV34OZ pin connector features a contact spacing of 2.54 mm and includes 34 pins arranged in 2 rows. Manufactured by econ connect, this component is ideal for applications requiring reliable interconnections in electronic assemblies. It is typically used in circuit board designs and comes in a 1-piece tray.
No. of rows 2
Board contact surface Gold plated
Case material PBT
Connection Cut & Clip
Connector contact surface Gold plated
Connector orientation Perpendicular (to the PCB)
Connector type Power strip
Contact material Brass
CS 2.54mm
Dim (L x W x H) 7 x 47.88 x 10.5 mm
Factory colour Black
Height 10.5mm
Length 7mm
Manufacturer part # PV34OZ
Max. temperature +105°C
Min. temperature -40°C
Misc Attribute PV34OZ
Nominal current 1A
Nominal voltage 500V AC
Packaging type Tray
Pins per row 17
RoHS-compliant Yes
Total number of pins 34
Type Pin connector
Width 47.88mm
