econ connect CSV4G/2 Pin Housing PCB 4 pins 2mm spacing bulk 1pc

Image Representative of Range

econ connect CSV4G/2 Pin Housing PCB 4 pins 2mm spacing bulk 1pc

econ connect
Standard range
Order Code:

02-7149

Brand: econ connect MPN: CSV4G/2
Qty Unit Price (Ex VAT)
1+ £0.060
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
323 in stock, despatched in 4 working days

The econ connect pin housing PCB CSV4G/2 features four pins with a contact spacing of 2 mm in a compact design. Manufactured by econ connect, this component is supplied in bulk as a single piece. Ideal for use in electronic circuit boards, this pin housing is suited for reliable and precise electrical connections.
No. of rows 1
Board contact surface Tin plated
Connection Solder pins
Connection angle 180°
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Pin strip, straight
Contact material Brass
CS 2mm
Factory colour White
Insulation material Nylon 6.6 UL 94V-2
Manufacturer part # CSV4G/2
Max. temperature 85°C
Min. temperature -25°C
Misc Attribute CSV4G/2
Nominal current 1A
Nominal current - rounded value 1A
Nominal voltage 100V
Packaging type Bulk
Pin shape Square
Pins per row 4
RoHS-compliant Yes
Total number of pins 4
Type Pin housing PCB
