econ connect BLG2X21 SIL Socket 2 rows 21 pins standard 1pc

Image Representative of Range

econ connect BLG2X21 SIL Socket 2 rows 21 pins standard 1pc

econ connect
Standard range
Order Code:

02-7022

Brand: econ connect MPN: BLG2X21
Qty Unit Price (Ex VAT)
1+ £0.631
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1,966 in stock, despatched in 4 working days

The econ connect SIL socket (standard) model BLG2X21 features two rows of 21 pins each, designed for effective connection in various electronic applications. Manufactured by econ connect, this socket is ideal for use in electronics assemblies where reliable and straightforward connections are required. It is commonly used in prototyping and development circuits, providing a dependable interface between components.
Case material PBT, UL94V-0
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector type Power strip, straight
Contact material Copper alloy
Contact surface Gold plated
CS 2.54mm
Dim (L x W x H) 53.84 x 53.84 x 8.5 mm
Factory colour Black
Height 8.5mm
Industrial packaging No
Length 53.84mm
Manufacturer part # BLG2X21
Max. temperature 105°C
Min. temperature -40°C
Misc Attribute BLG2X21
No. of rows 2
Nominal current 3A
Nominal current - rounded value 3A
Nominal voltage 1000V AC
Pin length (PCB) 3.15mm
Pin Ø 0.64mm
Pin shape Rectangular
Pins per row 21
RoHS-compliant Yes
Separable No
Total number of pins 42
Type SIL socket (standard)
Width 53.84mm
