The Eaton TM-1-15431/EZ is a versatile limit switch designed for 10 A, 500 V applications, featuring a rotary cam mechanism with 2 x 60° switching angles. The switch is available in a grey and black finish and is typically used in industrial settings for reversing, changeover, and selection operations. Eaton manufactures this robust and reliable switch, suitable for various electrical control applications.
| Type |
Limit switch |
| Complete device in housing |
FALSE |
| Connection |
Plug & Clip |
| Degree of protection (IP), front side |
IP65 |
| Degree of protection (NEMA), front side |
12 |
| Device construction |
Built-in device |
| Dim |
(L x W) 30 mm x 30 mm |
| Front shield size |
30x30 mm |
| Functions |
latch |
| IP rating |
IP65 |
| Length |
30mm |
| Max. rated operation voltage Ue AC |
500V |
| Max. temperature |
+50°C |
| Min. temperature |
-25°C |
| Misc Attribute |
TM-1-15431/EZ |
| Mounting Type |
Centre lock |
| Number of pins |
1 |
| Number of Poles |
1 |
| Number of switch positions |
3 |
| Operation type |
Toggle |
| Power |
3kW |
| Print motif |
Manual/0/Auto |
| Rated permanent current Iu |
10A |
| Suitable for distribution board installation |
FALSE |
| Suitable for floor mounting |
FALSE |
| Suitable for front mounting |
TRUE |
| Suitable for intermediate mounting |
FALSE |
| Switching angle |
2 x 60 ° |
| Switching current (max.) |
10A |
| Switching voltage |
500V |
| Type of control element |
Toggle |
| Type of switch |
Reverser |
| Width |
30mm |
| Width in number of modular spacings |
0 |
| With retraction in 0-position |
FALSE |
| With zero (off) position |
TRUE |
