Eaton 248851 Z-SCH24/25-40 remote switch 24V AC 25A 4 contacts

The Eaton Z-SCH24/25-40 is a remote switch designed for industrial applications with a nominal voltage of 24 V AC and a maximum switching current of 25 A. This relay module is crucial for controlling various electrical circuits, enhancing automation and safety in complex systems. It is typically used in environments requiring precise electrical control, such as manufacturing facilities and automation systems.

Type	Remote switch
Additional equipment possible	TRUE
Built-in depth	60mm
Connection	Screw terminal
Contact material	Cadmium free (Ag-alloy)
Contact type	4 makers
Degree of protection (IP)	IP40
Dim	(L x W x H) 60 x 35 x 87.50 mm
Factory colour	White
Height	87.50mm
Hum-free	FALSE
IP rating	IP40
Length	60mm
Max. incandescent lamp load	3000W
Max. load fluorescent lamp	1160VA
Max. load fluorescent lamp (Duo circuit)	2552VA
Max. load fluorescent lamp (parallel compensated)	1044VA
Misc Attribute	Z-SCH24/25-40
Nominal voltage	24V AC
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	4
Rated excitation voltage	20.4-26.4V
Rated operating voltage	440-440V
Rated operation current	25A
Slider for hand switch	FALSE
Switching current (max.)	25A
Switching voltage (max.)	440V AC
Voltage type (excitation voltage)	AC
Voltage type (operating voltage)	AC
Width	35mm
Width in number of modular spacings	2
With day/night function	FALSE
