Eaton 248848 Z-SCH230/25-04 remote switch 230V 25A 4 breakers noiseless

The Eaton Z-SCH230/25-04 remote switch operates at a nominal voltage of 230 to 240 V and can handle a maximum switching current of 25 A across four breakers. This industrial relay module is ideal for controlling electrical circuits remotely, ensuring efficient and safe operation in various applications. Typical uses include automated systems and electrical control panels in industrial settings.

Type	Remote switch
Additional equipment possible	TRUE
Built-in depth	60mm
Connection	Screw terminal
Contact material	Cadmium free (Ag-alloy)
Contact type	4 breakers
Degree of protection (IP)	IP40
Dim	(L x W x H) 60 x 35 x 87.50 mm
Factory colour	White
Height	87.50mm
Hum-free	FALSE
IP rating	IP40
Length	60mm
Max. incandescent lamp load	3000W
Max. load fluorescent lamp	1160VA
Max. load fluorescent lamp (Duo circuit)	2552VA
Max. load fluorescent lamp (parallel compensated)	1044VA
Misc Attribute	Z-SCH230/25-04
Number of contacts as normally closed contact	4
Number of contacts as normally open contact	0
Rated excitation voltage	195.5-253V
Rated operating voltage	440-440V
Rated operation current	25A
Slider for hand switch	FALSE
Switching current (max.)	25A
Switching voltage (max.)	440V AC
Voltage type (excitation voltage)	AC
Voltage type (operating voltage)	AC
Width	35mm
Width in number of modular spacings	2
With day/night function	FALSE
