Eaton 185140 C22-L-G-24-P62 Green Indicator Light 24V DC/AC

The Eaton C22-L-G-24-P62 is a planar green indicator light designed for 24 V DC/AC operation. It's suitable for use in control panels and industrial machinery to provide clear visual indicators. Renowned for its reliability, this indicator light is ideal for both commercial and industrial applications.

Type	Indicator light
Lamp/Lens Colour	Green
Colour front ring	Other
Colour lens	Green
Connection	Open end cable
Construction type lens	Round
Degree of protection (IP)	Other
Degree of protection (NEMA)	Other
Height opening	0mm
IP Rating	IP65, IP66, IP67
Material front ring	Plastic
Maximum Temperature	+70°C
Min. temperature	-30°C
Misc Attribute	C22-L-G-24-P62
Number of indicator lights	1
Operating Voltage	24V DC/AC
Panel Cutout Size	22.5mm
Rated operating voltage Ue	24-24V
Recess Diameter	22mm
Switch/button features	planar
Type of electric connection	Other
Type of lamp socket	LED
Type of lens	Flat
Voltage type	AC/DC
Width opening	0mm
With front ring	TRUE
With light source	TRUE
