Eaton 121734 PKE32 Overload relay 690V 1pc

Image Representative of Range

Eaton 121734 PKE32 Overload relay 690V 1pc

Eaton
Order Code:

02-5722

Brand: Eaton MPN: 121734 EAN-13: 4015081195442
Qty Unit Price (Ex VAT)
1+ £136.20
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
4 available to back orderBack-order availability date - 09/01/2026

Eaton manufactures the PKE32/XTU-32 overload relay, designed for use with 690 V systems. This safety device helps protect electrical circuits from overload by interrupting excessive current flow. Typical applications include industrial machinery and equipment that require reliable circuit protection.
Type Overload relay
Adjustment range undelayed short-circuit release 496-496A
Connection Screws
Degree of protection (IP) IP20
Depth 101mm
Device construction Built-in device fixed built-in technique
Dim (L x W x H) 102.5 x 45 x 102.5 mm
Height 102.5mm
IP Rating IP20
Length 102.5mm
Misc Attribute PKE32/XTU-32
Number of Poles 3
Overload release current setting 32-32A
Phase failure sensitive FALSE
Power loss 11.4W
Rated operating voltage 690-690V
Rated operation power at AC-3, 230 V 7.5kW
Rated operation power at AC-3, 400 V 15kW
Rated permanent current Iu 32A
Rated short-circuit breaking capacity Icu at 400 V, AC 100kA
Switch off technique Electronic
Switching Voltage 690V
Type of control element Turn button
Type of electrical connection of main circuit Screw connection
Width 45mm
With integrated auxiliary switch FALSE
With integrated under voltage release FALSE
With thermal overload protection FALSE
