EAO 61-4210.0 Series 61 Selector Switch-Actuator 2P maintain D18

EAO
MPN
61-4210.0
Brand
EAO
Order Code
53-0849
Country of Origin
Switzerland

Discontinued


The EAO Series 61 features a square shaped, 2 position push button maintained actuator.

Comprehensive and versatile. EAO offers the modular and recognised Series 61, a versatile and modular switch range for complex industrial applications.

Whether for applications with high temperature variations or mechanically demanding environments, the versatile Series 61 is always the first choice. Due to Series 61 modular construction and full selection of functions, you will find the right solution for your industrial application.


  • Switching Action: Maintained
  • Function: Selector Switch
  • Housing Material: Plastic
  • Housing Colour: Black
  • Mounting cut-out: 21.2 x 21.2 mm
  • Front Dimension: Ø 24 mm
  • Front IP protection: IP65
  • Weight 0.006 kg
Type Switch
Switch Function Maintained
Erp Ehq Custom Number 8538.9000
Erp Ehq Source Country Ch
Function Selector Switch
Lever Shape Short
Mechanical Lifetime According To Din/iec 60512-5-6 And En/iec 60947-5-1, 100 000 Cycles Of Operation
Operating Temperature – 25 °c … + 55°C
Output Hsd Yes
Rotary Positions 2 Positions
Switching Action Concat Rest - Maintained
Switching Angle Rotation Concat 90° Right
Weight 0.00503
