EAO 61-1110.0 Illuminated pushbutton-actuator mom D18

EAOs 61-1110.0 is an illuminated pushbutton actuator designed with a momentary switching action, suitable for applications where a reliable user interface is required. This component features a robust and durable design, ensuring longevity and sustainability in demanding environments. The pushbutton is designed with an 18 mm diameter, offering a compact footprint with ease of use for operators, and is equipped with high-visibility illumination for clear signalling. Typically, this device is utilised in control panels and instrumentation applications.

Type	Pushbutton
Contact Configuration	SPNO
Switch Function	Off-(On)
Mounting	Panel
Illumination	Clear
Panel Cutout Dimensions	16.2
Erp Ehq Custom Number	8538.9000
Erp Ehq Source Country	Ch
Front Bezel Colour	Black
Front Bezel Material	Plastic
Front Dimension Concat	Ø 18mm
Front Form	Round
Lens Illumination	Illuminated
Mechanical Lifetime	According To Din/iec 60512-5-6 And En/iec 60947-5-1, 2 Mil. Cycles Of Operation
Mounting Cut Out Dps Concat	Ø 16mm
Operating Temperature	– 25 °c … + 55°C
Output Hsd	Yes
Switching Action Concat	Momentary
Weight	0.00397
