DISPLAY VISIONS EADIP128J-6N5LW LCD Display 75x45.8x10.8mm white text on blue

Display Visions EADIP128J-6N5LW is an LCD display measuring 75 x 45.8 x 10.8 mm, offering white text on a blue background which makes it ideal for high-contrast visual applications. The display is a graphics liquid crystal display utilising super-twisted nematic (STN) technology, making it suitable for a variety of environments where good readability is required, such as industrial control panels, instrumentation, and telecommunication equipment. With its durable and compact design, the EADIP128J-6N5LW is engineered to provide reliable performance in settings that demand robust display solutions, ensuring clear and precise visual output even under challenging conditions. Display Visions' use of LED backlighting enhances visibility, allowing for use in low-light scenarios and supporting engineers in developing user interfaces that require consistent and efficient data presentation.

Type	LCD
Display Type	STN
Dimensions	(W x H x D) 75 x 45.8 x 10.8 mm
Depth	10.8mm
Height	45.8mm
Max. Current Consumption	5mA
Max. operating voltage	5V DC
Max. temperature	70°C
Maximum Temperature	70°C
Min. temperature	-20°C
Minimum Operating Temperature	-20°C
Operating Voltage	5 V DC (max)
Width	75mm
