Dehner Elektronik SS 30-24VL LED Driver 30W 1.25A 24V Surge Protection

Dehner Elektronik
Order Code:

02-4714

Brand: Dehner Elektronik MPN: SS 30-24VL Regular Size EAN-13: 4251125203692
Qty Unit Price (Ex VAT)
1+ £10.39
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
13 available to back orderBack-order availability date - 12/01/2026

The Dehner Elektronik SS 30-24VL Regular Size LED transformer is a constant voltage LED driver with a power rating of 30 W, outputting 24 V DC at 1.25 A. It features surge and overvoltage protection but is not dimmable. This LED power supply unit is typically used for powering LED strips and other LED applications.
Type LED transformer
Output Voltage 24V DC
Max Output Power 30W
Output Current 1.25A
Input Voltage 264V AC
Colour White
Connection Screw terminal
Dimensions (L x W x H) 123 x 44.6 x 19.2 mm
Height 19.2mm
IP Rating IP20
Length 123mm
Max. output current 1.25A
Max. temperature 45°C
Min. input voltage 180V AC
Min. temperature -20°C
Misc Attribute Constant voltage
Number of Inputs 1
Number of Outputs 1
Protection Class IP20
Test mark MM;SELV; TÜV; UKCA; CE
Width 44.6mm
