Dehner Elektronik SS 30-24VL LED Driver 30W 1.25A 24V Surge Protection

Dehner Elektronik
Order Code:

02-4714

Brand: Dehner Elektronik MPN: SS 30-24VL Regular Size EAN-13: 4251125203692
Qty Unit Price (Ex VAT)
1+ £10.39
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
17 in stock, despatched in 4 working days

The Dehner Elektronik SS 30-24VL Regular Size LED transformer is a constant voltage LED driver with a power rating of 30 W, outputting 24 V DC at 1.25 A. It features surge and overvoltage protection but is not dimmable. This LED power supply unit is typically used for powering LED strips and other LED applications.
Type LED transformer
Connection Screw terminal
Dim (L x W x H) 123 x 44.6 x 19.2 mm
Factory colour White
Height 19.2mm
Input voltage (max.) 264V AC
IP Rating IP20
Length 123mm
Max. output current 1.25A
Max. power 30W
Max. temperature 45°C
Min. input voltage 180V AC
Min. temperature -20°C
Misc Attribute Constant voltage
Number of Inputs 1
Number of Outputs 1
Operating Voltage 240V AC
Output current (max.) - rounded 1.25A
Output current (min.) 1.25A
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Power range 30 W (max)
Protection Class IP20
Test mark MM;SELV; TÜV; UKCA; CE
Width 44.6mm
