Dehner Elektronik SDS 100L-24 DC/DC Converter 100W 4.2A 1 piece

Dehner Elektronik SDS 100L-24 is a robust DC/DC converter designed to deliver 100 watts of power with an output current of 4.2 amperes, optimised for seamless integration into electronic systems that require efficient conversion of direct current. This converter boasts high reliability and precision, making it an ideal choice for demanding applications such as telecommunications, industrial automation, and transportation systems where stable and efficient power conversion is critical. The SDS 100L-24 model ensures effective current rectification and voltage regulation, thereby enhancing the performance and longevity of the host circuit. Its compact, print circuit design allows for easy integration onto the printed circuit board within compact and space-constrained environments. This converter exemplifies engineering excellence in maintaining high operational standards under varying load conditions.

Output Voltage	24V DC
Power Rating	100W
Connection	Screw terminal
Content	1
Dimensions	(L x W x H) 159 x 95 x 38 mm
Height	38mm
Input voltage (max.)	36V DC
Length	159mm
Max. operating temperature (derating)	70°C
Max. output current	4.2A
Min. input voltage	9.5V DC
Output current (max.) - rounded	4.2A
Output voltage (max.)	24V
Power	100W
Product Type	DC/DC converter
PSU features	DC-to-DC converter
Type	SDS 100L-24
Weight	460g
Width	95mm
