DEGSON DG332K-5.0-02P-12-00AH-1 Terminal 2mm² 2 Pins Blue 1pc

Image Representative of Range

DEGSON DG332K-5.0-02P-12-00AH-1 Terminal 2mm² 2 Pins Blue 1pc

Degson
Order Code:

02-4426

Brand: Degson MPN: DG332K-5.0-02P-12-00AH-1 EAN-13: 2050003352413
Qty Unit Price (Ex VAT)
20+ £0.294
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
134 in stock, despatched in 4 working days

The DEGSON DG332K-5.0-02P-12-00AH-1 is a blue screw terminal designed for 2 mm² wires with two pins, ideal for securing electrical connections on printed circuit boards. Manufactured by DEGSON, this terminal block provides robust wire protection and reliable performance. It is typically used in electrical and electronic circuits for efficient and secure connectivity.
No. of Ways 2
No. of Levels 1
Voltage Rating 300V
Current Rating 10A
Actuation direction Perpendicular (to the PCB)
AWG (min.) 28
AWG max. 16
Connector orientation Parallel (to the PCB)
Contact Material Brass tin plated
Cross section (flexible) (max.) 2mm²
Cross section (flexible) (min.) 0.08mm²
Cross section (inflexible) (max.) 2mm²
Cross section (inflexible) (min.) 0.08mm²
CS 5mm
Enclosure material Polyamide 6.6
Factory colour Blue
Height 10.80mm
Length 13.40mm
Min. stripping length 5mm
Misc Attribute DG332K-5.0-02P-12-00AH
Pins per row 2
Series DG350
Stripping length (max.) 6mm
Type Screw terminal
Width 10.00mm
Wire protection Yes
