DEGSON 2EDGRC-5.0-04P-14-00AH Socket Housing 4 Pins 5.0mm Spacing

Image Representative of Range

DEGSON 2EDGRC-5.0-04P-14-00AH Socket Housing 4 Pins 5.0mm Spacing

Degson
Order Code:

02-4284

Brand: Degson MPN: 2EDGRC-5.0-04P-14-00AH EAN-13: 2050003391276
Qty Unit Price (Ex VAT)
20+ £0.346
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
787 in stock, despatched in 4 working days

The DEGSON socket housing PCB, model 2EDGRC-5.0-04P-14-00AH, features four pins with a contact spacing of 5.0 mm. It is a pluggable, multi-pin connector ideal for use in electronics requiring reliable connections, such as control cabinets and power distribution. The basic housing and Combicon plug-in terminals of this component ensure efficient and secure installation.
Board contact surface Tin plated
Case Material PA 66 UL94V-0
Connection Print
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system board-to-board
Connector Type Socket, horizontal mount
Contact Material Brass
CS 5.0mm
Dim (L x W x H) 12.10 x 21.40 x 12.20 mm
Factory colour Green
Height 12.20mm
Length 12.10mm
Nominal Current 15A
Nominal current - rounded value 15A
Nominal Voltage 300V
Number of Rows 1
Pins per row 4
Total number of pins 4
Type Socket housing PCB
Width 21.40mm
