DEGSON 15EDGVC-2.5-03P-14-00AH-1 Socket Housing 3-Pin 2.5mm Spacing

Image Representative of Range

DEGSON 15EDGVC-2.5-03P-14-00AH-1 Socket Housing 3-Pin 2.5mm Spacing

Degson
Standard range
Order Code:

02-4224

Brand: Degson MPN: 15EDGVC-2.5-03P-14-00AH-1
Qty Unit Price (Ex VAT)
1+ £0.242
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
162 in stock, despatched in 4 working days

DEGSON manufactures the 15EDGVC-2.5-03P-14-00AH-1 socket housing PCB with three pins and a contact spacing of 2.50 mm. This component is ideal for providing secure and reliable connections in electronic circuits. It is commonly used in printed circuit boards for efficient electrical connectivity.
Board contact surface Tin plated
Case material PA 66 UL94V-0
Connection Print
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Power strip, straight
Contact material Copper alloy
CS 2.50mm
Dim (L x W x H) 8.10 x 11 x 10.10 mm
Factory colour Green
Height 10.10mm
Industrial packaging No
Insulation material PA 66 UL94V-0
Length 8.10mm
Manufacturer part # 15EDGVC-2.5-03P-14-00AH-1
Max. temperature +105°C
Min. temperature -40°C
Misc Attribute 15EDGVC-2.5-03P-14-00AH-1
No. of rows 1
Nominal current 4A
Nominal current - rounded value 4A
Nominal voltage 150V
Pin Ø 0.80mm
Pin shape Square
Pins per row 3
RoHS-compliant Yes
Series 15EDGVC
Total number of pins 3
Type Socket housing PCB
Width 11mm
