DEGSON 15EDGK-3.5-08P-14-00AH Pin Housing Cable 8 Pins 3.5mm Spacing

Image Representative of Range

DEGSON 15EDGK-3.5-08P-14-00AH Pin Housing Cable 8 Pins 3.5mm Spacing

Degson
Standard range
Order Code:

02-4128

Brand: Degson MPN: 15EDGK-3.5-08P-14-00AH
Qty Unit Price (Ex VAT)
1+ £1.77
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
274 in stock, despatched in 4 working days

DEGSON manufactures the 15EDGK-3.5-08P-14-00AH pin housing cable, featuring 8 pins with a contact spacing of 3.5 mm. This product, suitable for applications like elevators, uses pluggable screw terminals for reliable connections. Typical applications include plug-in terminals and combicon PCB terminals.
No. of rows 1
AWG (min.) 28
AWG max. 16
Case material PA 66 UL94V-0
Compatible with (details) 28 - 16
Connection Screw terminal
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Plug, straight
Contact material Phosphor bronze
CS 3.5mm
Dim (L x W x H) 15.60 x 28.80 x 11.10 mm
Factory colour Green
Height 11.10mm
Length 15.60mm
Manufacturer part # 15EDGK-3.5-08P-14-00AH
max. cross section 1.5mm²
Min. cross section 1mm²
Misc Attribute 15EDGK-3.5-08P-14-00AH
Nominal current 8A
Nominal current - rounded value 8A
Nominal voltage 300V
Pins per row 8
RoHS-compliant Yes
Stripping length (max.) 7.00mm
Total number of pins 8
Type Pin housing cable
Width 28.80mm
