DEGSON 15EDGA-3.81-10P-14-00AH-1pcB Pin Housing 3.81mm 10 Pins

Name: DEGSON 15EDGA-3.81-10P-14-00AH-1pcB Pin Housing 3.81mm 10 Pins
Brand: Degson
Price: 2.41 GBP
Availability: InStock

Standard range

Order Code:

02-4104

Brand: Degson MPN: 15EDGA-3.81-10P-14-00AH-1

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (17)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£2.41

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

163 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The DEGSON 15EDGA-3.81-10P-14-00AH-1 pin housing PCB features 10 pins with a contact spacing of 3.81 mm. It is designed for secure and reliable electrical connections on printed circuit boards. Typically used in industrial and electrical applications, it ensures efficient connectivity and organisation of wiring systems.

Board contact surface	Tin plated
Case material	PA 66 UL94V-0
Connection	Print
Connector contact surface	Tin plated
Connector orientation	Parallel (to the PCB)
Connector system	wire-to-board
Connector type	Plug, horizontal mount
Contact material	Phosphor bronze
CS	3.81mm
Dim	(L x W x H) 14.50 x 42.43 x 6.65 mm
Factory colour	Green
Height	6.65mm
Industrial packaging	No
Insulation material	PA 66 UL94V-0
Length	14.50mm
Manufacturer part #	15EDGA-3.81-10P-14-00AH-1
Max. temperature	+105°C
Min. temperature	-40°C
Misc Attribute	15EDGA-3.81-10P-14-00AH-1
No. of rows	1
Nominal current	8A
Nominal current - rounded value	8A
Nominal voltage	300V
Pin Ø	0.60mm
Pin shape	Rectangular
Pins per row	10
RoHS-compliant	Yes
Series	15EDGA
Total number of pins	10
Type	Pin housing PCB
Width	42.43mm
