Connfly DS1021-2*20SF11 Pin Strip Standard 2 Rows 20 Pins per Row

Image Representative of Range

Connfly DS1021-2*20SF11 Pin Strip Standard 2 Rows 20 Pins per Row

Connfly
Standard range
Order Code:

08-7957

Brand: Connfly MPN: DS1021-2*20SF11 EAN-13: 2050003635264
Qty Unit Price (Ex VAT)
1+ £0.378
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
965 in stock, despatched in 4 working days

The Connfly DS1021-2*20SF11 is a standard pin strip with two rows and 20 pins per row. Manufactured by Connfly, it is designed for reliable electrical connectivity in circuit board assemblies. This pin strip is typically used in electronic and electrical applications where robust and durable connections are necessary.
Type Pin strip (standard)
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector type Pin strip, straight
Contact surface Gold plated
CS 2.54mm
Dim (L x W) 50.80 mm x 5 mm
Factory colour Black
Industrial packaging No
Length 50.80mm
Manufacturer part # DS1021-2*20SF11
Max. temperature +85°C
Min. temperature 0°C
Misc Attribute DS1021-2*20SF11
No. of rows 2
Pin length (PCB) 3mm
Pin length (receptacle) 6.10mm
Pin Ø 0.64mm
Pin shape Square
Pins per row 20
RoHS-compliant Yes
Separable Yes
Socket shape Square
Total number of pins 40
Width 5mm
