Cimco 180490 Ring Terminal 95mm² Dia10.5mm Non-Insulated Metal 1 piece

Image Representative of Range

Cimco 180490 Ring Terminal 95mm² Dia10.5mm Non-Insulated Metal 1 piece

Cimco
Standard range
Order Code:

11-6026

Brand: Cimco MPN: 180490 EAN-13: 2050001250179
Qty Unit Price (Ex VAT)
1+ £1.94
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
61 in stock, despatched in 4 working days

The Cimco 180490 ring terminal is a non-insulated metal connector designed for a max cross-section of 95 mm² with a hole diameter of 10.5 mm. Produced by Cimco, it serves as a reliable crimp connector and is commonly used in automotive and electrical applications. Ideal for use where solder-free connections are required, it ensures secure and efficient electrical terminations.
Contact material Cathode copper, tin plated
Cross section 95mm²
Cross-section range 95 mm² (max)
Factory colour Metal
Hole Ø 10.5mm
Insulation type Not insulated
Manufacturer part # 180490
Material (details) Cu-ETP according to DIN EN 13600
max. cross section 95mm²
Misc Attribute 180490
RoHS-compliant Yes
Size M10
Support sleeve No
Thread Size M10
Type Ring terminal
