Cimco 180314 Bullet Receptacle 4-6mm² 5mm Pin Insulated Yellow

Image Representative of Range

Cimco 180314 Bullet Receptacle 4-6mm² 5mm Pin Insulated Yellow

Cimco
Standard range
Order Code:

11-5975

Brand: Cimco MPN: 180314 EAN-13: 2050001251398
Qty Unit Price (Ex VAT)
1+ £0.297
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
81 in stock, despatched in 4 working days

The Cimco 180314 bullet receptacle is a yellow insulated crimp connector designed for wire sizes 4 mm² and 6 mm² with a pin diameter of 5 mm. Manufactured by Cimco, it serves as a blade terminal and is typically used in electrical wiring applications to facilitate secure and reliable connections. This durable, single-piece component is essential for various electrical and electronic installations.
AWG (min.) 12
AWG max. 10
Contact material Brass tin plated
Cross section 4 - 6mm²
Cross-section range 4 - 6 mm²
Factory colour Yellow
Insulation material PA
Insulation type Insulated
Manufacturer part # 180314
max. cross section 6mm²
Min. cross section 4mm²
Misc Attribute 1 Sleeves
Misc Attribute 2 180314
Pin Ø 5mm
RoHS-compliant Yes
Support sleeve No
Temperature range -60 - +105°C
Type Bullet receptacle
