Cimco 180302 Bullet Connector 1.5-2.5mm² 5mm Dia Partially Insulated Blue

Image Representative of Range

Cimco 180302 Bullet Connector 1.5-2.5mm² 5mm Dia Partially Insulated Blue

Cimco
Standard range
Order Code:

11-5971

Brand: Cimco MPN: 180302 EAN-13: 2050002976948
Qty Unit Price (Ex VAT)
1+ £0.178
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
200 in stock, despatched in 4 working days

The Cimco bullet connector 180302 is a crimp connector suitable for wire sizes 1.50 mm² to 2.50 mm², featuring a pin diameter of 5 mm and partial blue (transparent) insulation. This product is typically used for connecting electrical wires in automotive and electronic applications, providing a reliable and robust connection. Manufactured by Cimco, it is designed for ease of use and secure connectivity.
Type Bullet connector
AWG (min.) 16
AWG max. 14
Contact material Brass tin plated
Cross-section range 1.50 - 2.50 mm²
Factory colour Blue (transparent)
Insulation PA (polyamide, nylon), halogen free
Insulation material PA
Insulation type Partially insulated
Manufacturer part # 180302
Material (details) CuZn
max. cross section 2.50mm²
Min. cross section 1.50mm²
Misc Attribute 180302
Pin Ø 5mm
RoHS-compliant Yes
Support sleeve No
Temperature range -60 - +105°C
