Cimco 180282 Blade Receptacle 6.3mm Width 0.8mm Thick Insulated Blue

Image Representative of Range

Cimco 180282 Blade Receptacle 6.3mm Width 0.8mm Thick Insulated Blue

Cimco
Standard range
Order Code:

11-5962

Brand: Cimco MPN: 180282 EAN-13: 2050001251268
Qty Unit Price (Ex VAT)
1+ £0.202
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
326 in stock, despatched in 4 working days

Cimco's 180282 is a partially insulated crimp connector with a 6.3 mm width and 0.8 mm thickness, designed for 180° blade terminal receptacles. Featuring a blue insulation, it is suitable for electrical connections that require reliable and secure joining. Typically used in automotive and electronic applications, this connector ensures efficient transmission of electrical signals.
Connection angle 180°
Connector thickness 0.8mm
Connector width 6.3mm
Contact material Brass tin plated
Cross section 1.5 - 2.5mm²
Cross-section range 1.50 - 2.50 mm²
Factory colour Blue
Insulation Halogen-free PA insulation (polyamide)
Insulation material Polyamide 6.6
Insulation type Partially insulated
Manufacturer part # 180282
Material (details) CuZn (brass)
max. cross section 2.50mm²
Min. cross section 1.50mm²
Misc Attribute 1 6.3 x 0.8 mm
Misc Attribute 2 180282
Size 6.3 x 0.8 mm
Temperature range -60 - +105°C
Type Blade receptacle
